Multifunctional Cutting Sliding Table Saw Machine with Automatic lifting

Graphic
Detail

Multifunctional Cutting Sliding Table Saw Machine with Automatic lifting

Suitable for cutting MDF,Particleboard,PVC board,plywood.ABS board,solid wood board,organic glass board.

1. European-style double-layer push table, round bar guide rail, with internal step-by-step locking function

2. Suspended body to prevent deformation

3. Square tube body, laser cutting, high precision, approximately 5mm thick steel plate with gantry milling machine body, length 1.95 meters

4. Uses Japanese NACHI Futsukoshi bearings, high precision and low noise

5. 5.5kw main saw motor power + 1.1kw auxiliary saw motor power, the motors are Qingdao Jubang brand pure copper motors (if refurbished or aluminum core motors are used, ten times the penalty will be paid)

6. 45-degree digital display, electric lifting of the main saw

7. 45-degree saw blade standard configuration includes pusher blade, divider blade, and dust cover.

8. 1.75-meter extendable European-style straightedge; smooth push-pull operation with large European-style fixed length seat.

9. 100mm aluminum core pull design; 4 eccentric wheels on the rotating arm.

10. Hanging material support bracket installation; enlarged slider for enhanced durability and resistance to deformation.

11. Standard configuration includes oiler.

12. Enlarged auxiliary workbench.

13. Equipped with adjustable feet.

Model	MJ-45YA	MJ-45YAS	MJ-45YZ	MJ-45YZS	MJ6132D
Sliding table width	375mm	375mm	375mm	375mm	375mm
Maximum sawing length	1600/2800/3000/3200mm	1600/2800/3000/3200mm	2800/3000/3200mm	3000/3200mm	3200mm
Vertical sawing height	70mm	70mm	70mm	80mm	80mm
Longitudinal guide ruler travel	1200mm	1250mm	1300mm	1300mm	1300mm
Lifting type of main saw	hand-actuated lifting (update optional)	hand-actuated lifting (update optional)	Electrical lifting	Electrical lifting	Electrical lifting
Digital display	Dial display	Dial display	Digital display	Digital display	Digital display
Tiltable range	0-45°	0-45°	0-45° （update electrical tilt optional）	0-45° （update electrical tilt optional）	0-45° （update electrical tilt optional）
Power of main saw	4KW	5.5KW	5.5KW	5.5KW	5.5KW
Size of main saw	300 Φ30mm	300 Φ30mm	300 Φ30mm	300 Φ30mm	400 Φ30mm
Power of auxiliary saw	0.75KW	1.1KW	1.1KW	1.1KW	1.1KW
Size of auxiliary saw	120 Φ20mm	120 Φ20mm	120 Φ20mm	120 Φ20mm	120 Φ20mm
Total power	4.75KW	6.6KW	6.6KW	6.6KW	6.6KW
Dimension of machine	28503150890mm	30503150890mm	30503150920mm	32503150920mm	32503150920mm
Net weight	450KG	560KG	650KG	680KG	750KG
Length of machine body	1800mm	1950mm	1950mm	1950mm	1950mm
Width of machine body	1000mm	1000mm	1000mm	1000mm	1000mm
Thickness of machine body	4mm	5mm	5mm	5mm	6mm+table 10mm
Structure of machine body	Steel plate	Steel plate	Square tube	Square tube	Square tube
Cast iron table size	995*550mm	1020*635mm	995*550mm	1020*635mm	910*620mm
Large auxiliary working table	720*480mm	700*655mm	970*775mm	1020*760mm	915*800mm
Small auxiliary working table	600*475mm	580*550mm	780*605mm	580*550mm	780*605mm
Large Sliding Fence length	1650mm	1650mm	1750mm	1800mm	1800mm
Aluminum alloy baffle	1150mm	1150mm	1150mm	1150mm	1150mm
Template Shaft diameter	40mm	40mm	40mm	45mm	45mm
Template Shaft length	1300mm	1300mm	1300mm	1500mm	1500mm

①machine body：

Custom-designed extended and thickened body/base for large gantry milling machines. The body length is extended by 1950mm, the body width is 1000mm, and it adopts square tube body technology with a body thickness of 5mm. The table saw base is processed using EU standard gantry milling equipment, and the milling is completed in one go, ensuring that there are no errors or vibrations in the table. Compared with other common screw rod fixed structures, it guarantees the stability and accuracy of the machine body.

②Widened cast iron tabletop and auxiliary workbench:

The enlarged, widened, and thickened cast iron worktable, along with the fully enclosed double auxiliary workbench, allows one person to easily cut large plates. Cast iron worktable dimensions: 995*550mm; Large auxiliary workbench: 970*775mm; Small auxiliary workbench: 780*605mm.

③Large Sliding Fence:

The straightedge is a 1.75m extended European-style straightedge, which can be extended and retracted, ensuring stability and preventing displacement. This effectively guarantees stability, precision, and smooth operation during the board cutting process.

④Double-layer sliding table：

European-style heavy-duty double-layer sliding table saw with step-by-step locking mechanism。

⑤Double saw blade：

The double-blade structure prevents chipping and the saw blades are adjustable to a 45-degree tilt. The machine uses a double-blade structure: the smaller blade marks and grooves, while the larger blade cuts the board. This design prevents chipping and burrs during cutting.

⑥Control switch：

Integrated control panel, simple and safe, digital display, electric lifting of main saw.

⑦pure copper motor：

It adopts a national standard copper motor with a main motor power of 5.5KW and a small motor power of 1.1KW, which provides powerful cutting, high starting torque, durability and no jamming.The motor is mounted using a suspended frame structure. The frame is stable and will not deform.

⑧Oil injection system：

Equipped with an oil injection device, it is mainly used for lubricating internal oil passages and protecting internal components.

⑨Adjustable feet：

Uneven ground can be adjusted using the leveling feet, which stabilize the machine and provide excellent fixation.

Suitable for cutting MDF,Particleboard,PVC board,plywood.ABS board,solid wood board,organic glass board.
